UltraClean™ Atmospheric II



Designed to meet ISO 14644 Class 5 Cleanroom applications.

These systems are Ideal for cleanrooms air showers and pharmaceutical applications. Available in single slide or biparting configurations, surface applied or mounted within wall opening. Systems Include:

  • Series 2000B belt drive
  • Sloped Stops

Selection Guide

General Installation

General Operation

Test Report



TYPE  BREAKOUT  INSTALLATION HAND  DETAILS  SPECS  CAD
 Single  None - Type 010  Mounted within Wall Opening  O-X or X-O   C7.04
 Single  None - Type 010 Surface Applied  P-X or P-X   C7.05
 Biparting  None - Type 010 Mounted within Wall Opening  O-X-X-O   C7.06
 Biparting  None - Type 010 Surface Applied  P-X-X-P   C7.07
 Single  Partial - Type 110 Mounted within Wall Opening  O-SX or SX-O   C7.08
 Single  Partial - Type 110 Surface Applied  P-SX or SX-P   C7.09
 Biparting  Partial - Type 110 Mounted within Wall Opening  O-SX-SX-O   C7.10
 Biparting  Partial - Type 110 Surface Applied  P-SX-SX-P   C7.11
